| Recording | ||
| Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 | |
| Resolution | When 1080p Lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF | |
| Bit Rate | 32 Kbps to 10 Mbps | |
| Others | Frame Rate Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP lite"15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF"25 fps (P)/30 fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF"15 fps For 1080p stream access: 1080p/720p"15 fps; VGA/WD1/4CIF/CIF"25 fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF"25 fps (P)/30 fps (N) When 1080p Lite mode enabled: 4 MP lite/3 MP"15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF"25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF"12 fps; CIF"25 fps (P)/30 fps (N) Dual-stream Support Stream Type Video, Video & Audio Audio Compression G.711u Audio Bitrate 64 Kbps |
|
| Video Detection And Alarm | ||
| Alarm Input | N/A | |
| Network | ||
| Ethernet Port | 1, RJ45 10/100/1000 Mbps self-adaptive Ethernet interface | |
| Network Function | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF | |
| Storage | ||
| Internal HDD | 2 SATA interfaces | |
| Auxiliary Interface | ||
| USB | Front panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0 | |
| RS485 | RS-485 (half-duplex) | |
| Power | ||
| Power Supply | 12 VDC, 5 A | |
| Power Consumption | ≤ 40 W | |
| Construction | ||
| Dimensions | 380 × 320 × 48 mm (15.0” × 12.6” × 1.9”) | |
| Net Weight | ≤ 2.1 kg (4.6 lb) | |
| Warranty | ||
| Manufacturing Warranty | 01-Year Warranty | |
