| General | ||
| Casing | Plastic | |
| Dimensions | 138.8 mm × Ø70 mm (5.47" × Ø2.76") | |
| Weight | Approx. 270 g (0.60 lb.) | |
| Pan/Tilt/Rotation | Pan: 0 to 360°, Tilt: 0 to 90°, Rotate: 0 to 360° | |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation) | |
| Power Supply | 12 VDC ± 25%, Max. 3.2 W | |
| Power Consumption | Max. 3.3 W | |
| Camera | ||
| Image Sensor | 3K CMOS | |
| Effective Pixels | 2960 (H) × 1665 (V) | |
| Electronic Shutter Speed | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s | |
| Minimum Illumination | 0.01 Lux " (F2.0, AGC ON), 0 Lux with IR | |
| IR Distance | Up to 30 m IR distance for bright night imaging Up to 20 m white light distance for bright night imaging |
|
| Lens | ||
| Lens Type | 2.8 mm and 3.6 mm fixed focal lens | |
| Mount Type | M12 | |
| Focal Length | 2.8 mm, horizontal FOV: 105°, vertical FOV: 62°, diagonal FOV: 132° 3.6 mm, horizontal FOV: 92°, vertical FOV: 48°, diagonal FOV: 112° | |
| Video | ||
| Resolution | 2960 × 1665 | |
| Frame Rate | TVI: 3K"20 fps, 4 MP"25 fps/30 fps, 1080p"25 fps/30 fps AHD: 4 MP"25 fps/30 fps CVI: 4 MP"25 fps/30 fps CVBS: PAL/NTSC | |
| Video Output | 4 in 1 video output (switchable TVI/AHD/CVI/CVBS) | |
| Day/Night | ICR | |
| Warranty | ||
| Warranty | 1 year | |
